P0675 on the 6.4L Power Stroke points to a problem in the glow plug circuit for cylinder 5. Glow plugs help this engine start and run smoothly when cold, so a failed plug or circuit shows up most in cold-weather starting. Here is how to diagnose and fix it.
What P0675 means
P0675 is defined as Glow Plug Circuit Cylinder 5. The 6.4L Power Stroke uses individual glow plugs controlled through a glow plug control module. The module monitors each plug circuit; when it detects an open, short, or out-of-range resistance on the cylinder 5 circuit, it sets P0675. The code identifies the circuit, not necessarily the plug itself, so the wiring and module also matter.
Common causes
- Failed glow plug on cylinder 5 (open or shorted)
- Damaged or corroded glow plug wiring or connector
- Faulty glow plug control module output for that cylinder
- High resistance from corrosion at the plug terminal
- Chafed harness shorting to the cylinder head
Symptoms
- Check engine light with stored P0675
- Hard starting when cold
- Rough idle or a miss right after a cold start
- White smoke on cold startup
- Wait-to-start behavior or extended cranking in cold weather
How to diagnose it
With the engine off, measure the resistance of the cylinder 5 glow plug; a good plug reads low resistance, while an open plug reads infinite. Compare it to the other plugs. Inspect the connector and harness for corrosion or damage, and check the terminal is clean and tight. If the plug and wiring test good, test the control module output for that cylinder. Because access on the 6.4L can be tight, confirm the fault before removing parts unnecessarily.
How to fix it
Replace the cylinder 5 glow plug if it tests open, shorted, or out of range, using care not to break the plug on removal. Repair corroded or damaged wiring and clean the terminal for a solid connection. Replace the glow plug control module if its output for that circuit has failed. After the repair, clear the code and verify the circuit reads correctly and cold starts improve.
Frequently asked questions
Will P0675 keep my 6.4 from starting?
One bad glow plug usually causes hard cold starts and a rough cold idle rather than a no-start, but multiple failed plugs can make cold starting very difficult.
Should I replace all glow plugs at once?
If one has failed at high mileage, many owners replace the full set since the others are likely close behind, which also saves repeat labor.
Is it the plug or the module?
Test the individual plug resistance and wiring first. If those are good, the control module output for that cylinder is the next suspect.
