Garrett 2022+ Audi/Volkswagen Golf R 2.0L EA888 Evo4 GT2: Specs, Fitment, and Is It Worth It

The Garrett PowerMax turbocharger for the 2022+ Audi and Volkswagen Golf R 2.0L EA888 Evo4 is a direct-fit performance upgrade for MQB Evo platform owners who want more power than the factory turbocharger can deliver. The 2022+ Golf R and Audi S3 use the fourth-generation EA888 engine -- the EA888 Evo4 -- with a revised cylinder head, revised port injection and direct injection arrangement, and a factory turbocharger tuned for 315 horsepower. Garrett offers two direct-fit PowerMax options for this engine: the GT2260S for moderate power builds and the GT2563S for builds targeting higher peak output. Both are engineered to install in the factory turbocharger location without exhaust fabrication, custom intake piping, or oil line modification. This guide covers the specifications, fitment, and build suitability of the Garrett GT2563S and GT2260S PowerMax turbos for the EA888 Evo4 platform.

Fitment: Garrett PowerMax for 2022+ Golf R and Audi EA888 Evo4

Confirmed fitment for the Garrett PowerMax EA888 Evo4 direct-fit turbos:

• 2022+ Volkswagen Golf R (Mk8) with 2.0L EA888 Evo4 TSI engine
• 2022+ Audi S3 with 2.0L EA888 Evo4 TFSI engine (where applicable by market)

Both the GT2563S (921474-5001S) and the GT2260S (917056-5002S) are direct-fit units for the EA888 Evo4. They install at the factory turbocharger mounting location using the factory exhaust manifold connection, factory oil feed and return ports, and factory coolant connections. The intake connection mates to the factory charge pipe without modification, and the electronic boost control solenoid interface is retained so the factory ECU continues to manage boost normally at factory calibration. No additional fabrication is required for a base installation on either turbocharger.

The EA888 Evo4 uses a twin-scroll turbocharger configuration in the factory unit. Both Garrett PowerMax options retain the twin-scroll turbine inlet to preserve the low-RPM response and cylinder isolation benefits the factory twin-scroll design provides. Substituting a single-scroll turbocharger on a twin-scroll manifold reduces low-RPM torque delivery, which is why the Garrett direct-fit units maintain the correct turbine inlet geometry for this engine.

Top Picks: Garrett PowerMax GT2563S and GT2260S for the EA888 Evo4

The Garrett 2022+ Audi/Volkswagen Golf R 2.0L EA888 Evo4 GT2563S PowerMax Direct-Fit Turbocharger (921474-5001S) is the higher-power option for the EA888 Evo4 platform, and the correct choice for a Golf R or S3 build targeting Stage 2 or higher output levels. The GT2563S uses a larger compressor wheel than the GT2260S, which raises the peak mass flow rate and extends the compressor's efficiency island higher into the boost range. On a fully supported Stage 2 build -- upgraded intercooler, supporting ECU calibration, and intake and exhaust modifications -- the GT2563S is sized to support the airflow demand those modifications create at elevated boost levels. The larger compressor does require a supporting tune that accounts for the GT2563S's different compressor characteristics compared to the factory turbo; the full performance benefit is not accessible at factory ECU calibration.

The Garrett PowerMax GT2260S Direct Fit Performance Turbocharger 2022+ Audi/Volkswagen 2.0L EA888 Evo4 (917056-5002S) is the stage 1 option for the EA888 Evo4, sized for builds where the goal is a moderate power increase over the factory turbo with improved surge margin and compressor durability. The GT2260S compressor map overlaps closely with the factory unit's operating range but extends efficiency further into the elevated boost range a Stage 1 tune commands. It is more forgiving at factory-adjacent boost levels than the GT2563S and is the correct selection for an EA888 Evo4 build that prioritizes drivability and street manners over maximum peak output. Browse the complete Garrett PowerMax EA888 turbocharger catalog for both options with full specification listings.

Match to the Build

• Stock 2022+ Golf R or S3 at Stage 1 power level: The GT2260S is the correct PowerMax for a Stage 1 build on the EA888 Evo4 -- an ECU tune with a supporting intake is all that is required alongside the turbo, and the GT2260S's compressor map is well-suited to the boost levels and airflow a Stage 1 calibration targets on this engine
• Stage 2 EA888 Evo4 build with intercooler and exhaust: The GT2563S is the turbocharger for a Stage 2 build that includes an upgraded front-mount intercooler, high-flow exhaust, and a supporting ECU calibration; the larger compressor handles the increased airflow demand of a Stage 2 build without the efficiency loss the factory turbo and the GT2260S experience at Stage 2 boost levels
• High-mileage EA888 Evo4 due for turbo replacement: Either PowerMax option serves as a factory-footprint replacement for a 2022+ Golf R or S3 with a worn factory turbocharger; the GT2260S is the closer match to factory performance characteristics, while the GT2563S provides a performance step alongside the replacement if the build will eventually reach Stage 2
• Track-focused EA888 Evo4 build prioritizing sustained boost stability: Both PowerMax options provide improved surge margin over the factory turbocharger, which matters on a track build where the turbocharger operates near its boost target for extended periods; the GT2563S provides the larger surge margin of the two for a track-focused application with aggressive boost targets

Signs the EA888 Evo4 Factory Turbocharger Needs Attention

• Compressor surge at elevated boost on a tuned EA888 Evo4 -- a rhythmic flutter or surge sound from the intake under hard acceleration indicates the factory turbocharger operating past its surge line at the boost level the tune commands; characteristic of the factory unit at Stage 1 or higher boost targets; the PowerMax GT2260S or GT2563S moves the surge line outward and eliminates this condition
• Boost target not maintained above a certain RPM on a tuned car -- the factory compressor reaching its flow limit before the engine completes its power band; the ECU logs showing actual boost falling below requested boost at high RPM; the GT2563S addresses this by raising the compressor's rated flow ceiling
• Oil consumption or blue smoke under boost on deceleration -- turbocharger compressor seal wear allowing oil into the intake; more common on high-mileage EA888 platforms that have accumulated boost cycles; requires turbocharger replacement
• Boost response that feels noticeably slower than when the car was new -- compressor efficiency degradation from bearing wear and wheel erosion; a PowerMax replacement restores the spool characteristics the factory turbo had when new, and the improved surge margin means the replacement will sustain better efficiency at elevated boost than the original

Frequently Asked Questions

Do the Garrett GT2563S and GT2260S require a tune on the 2022+ Golf R?

An ECU tune is strongly recommended for both. At factory calibration, the ECU targets factory boost levels and the PowerMax turbos will produce factory-level boost without a tune -- but the performance advantage of the larger compressor is not accessible without a calibration that raises the boost target to take advantage of the expanded compressor map. The GT2563S in particular requires a supporting tune to operate correctly at its intended performance level; it is not designed as a drop-in replacement at factory boost. The GT2260S is more forgiving at factory-adjacent boost levels but still benefits substantially from a Stage 1 tune.

What supporting modifications does the GT2563S need on the EA888 Evo4?

A Stage 2 GT2563S build on the EA888 Evo4 typically includes: an upgraded front-mount intercooler to handle the increased compressed air volume at elevated boost, a high-flow intake for reduced restriction at the compressor inlet, a supporting ECU calibration, and a downpipe or high-flow exhaust to reduce turbine backpressure. The GT2563S can be installed without all of these at once, but achieving its full potential requires the supporting hardware to remove the intake and exhaust flow restrictions that limit the larger compressor from operating in its efficient range.

Bottom Line

The Garrett PowerMax turbos for the 2022+ Audi and Volkswagen Golf R EA888 Evo4 offer two direct-fit upgrade paths for the MQB Evo platform. The GT2260S is correctly sized for Stage 1 builds where street drivability and a moderate power increase are the target. The GT2563S covers Stage 2 and higher builds with a larger compressor that sustains efficiency at the elevated boost levels a fully modified EA888 Evo4 commands. Both install in the factory location without fabrication and retain the factory twin-scroll turbine inlet for correct low-RPM response.
