The best Power Stroke turbocharger upgrade depends on the generation in the driveway and how the truck is used. Ford has produced three distinct Power Stroke diesel platforms -- the 7.3L, 6.0L, and 6.7L -- and each one responds differently to a turbo upgrade. The 7.3L uses a single fixed-geometry turbocharger with strong spool characteristics that a larger CHRA unit extends cleanly. The 6.0L uses a variable geometry turbo that is a known failure point and benefits significantly from a quality replacement. The 6.7L uses a sophisticated variable geometry system that Garrett and ATS Diesel have now built direct-fit PowerMax upgrades around. This guide covers the best Power Stroke turbocharger options for each generation so you can make the right call for the build.
Power Stroke Turbo Sizing by Generation
Turbo selection on the Power Stroke platform is generation-specific. Using the wrong unit or guessing at fitment produces boost control problems, poor spool characteristics, and hardware incompatibilities that cost time and money to sort out.
7.3L Power Stroke (1994.5-2003): The 7.3L uses a single turbocharger with a fixed compressor and turbine wheel. Stock units are sized for reliability and towing response at factory power levels. An upgraded CHRA or full turbo kit from Garrett extends airflow capability for builds running a chip or tuner, allowing the engine to make more power without the heat and smoke that come from pushing a stock wheel past its efficiency range.
6.0L Power Stroke (2003-2007): The 6.0L uses a Garrett GT3788VA variable geometry turbo. This unit is frequently cited in 6.0L reliability discussions -- the variable vane actuator is sensitive to oil quality and EGR soot contamination, and a failed VGT results in limp mode, low power, and elevated EGTs. A fresh Garrett replacement or upgraded PowerMax unit is the correct solution for a 6.0L with VGT problems or a 6.0L build targeting more power.
6.7L Power Stroke (2011-2019): The 6.7L uses a compound turbo arrangement from the factory, with a high-pressure and a low-pressure turbo working together. Single-turbo conversion and high-pressure turbo upgrades are the most common modification paths. Garrett's PowerMax AVNT3788R is the leading direct-fit upgrade for the 2015-2019 model years, sized to support a tuned 6.7L without requiring custom piping or modifications to the factory charge air routing.
Top Picks for Power Stroke Turbocharger Upgrades
For the 6.7L Power Stroke (2017-2019), the Garrett PowerMax AVNT3788R (951206-5001S) is the leading direct-fit performance upgrade. Garrett spec the 63.5mm compressor wheel for a meaningful airflow increase over the stock unit while maintaining the variable geometry turbine for strong low-RPM spool and towing response. It bolts directly to the factory location with no custom plumbing. For the 2015-2016 6.7L, the Garrett PowerMax AVNT3788R (951205-5001S) is the same specification, calibrated for the slightly different inlet geometry of the earlier build dates.
For a high-output 6.7L stage 2 build, the ATS Diesel Aurora 3000 VFR Stage 2 Turbo (202-402-3416) is the alternative for owners targeting more airflow than the Garrett PowerMax provides. The Aurora 3000 uses ATS's variable flow rate design for a wider efficiency range, and it is built to handle sustained high-output use that pushes the limits of the factory turbo hardware.
For the 6.0L Power Stroke (2004-2007), the Garrett PowerMax GT3788VA (772441-5002S) is the direct-fit upgrade, built on the GT3788VA platform with Garrett's updated internal components for better efficiency and durability over the original unit. For 2003 model-year 6.0L trucks with the early build-date inlet configuration, the Garrett GT3788VA (777469-5002S) is the correctly matched unit -- do not substitute the later part number on a 2003 build-date truck without confirming inlet compatibility.
For the 7.3L Power Stroke (1999.5-2003), the Garrett GTP38R Turbo Kit (739619-5004S) is the direct-fit high-performance unit. It replaces the stock GTP38 CHRA with an upgraded compressor and turbine wheel sized for builds running a chip or performance tune, improving top-end airflow and high-RPM response without sacrificing the low-RPM pull that makes the 7.3L a strong tow platform.
Match the Turbo to the Build
Selecting the best Power Stroke turbocharger means matching the turbo's compressor map to the actual airflow demand of the build:
- Tune level: A Garrett PowerMax or ATS Aurora unit is sized for a tuned engine. Running a performance turbo on a stock calibration gains nothing useful -- the tune drives the boost target and fueling that the turbo responds to.
- Injector sizing: On a 6.7L build, a turbo upgrade pairs with an injector upgrade. A larger turbo on stock injectors runs out of fuel before it runs out of air. Match the turbo tier to the injector tier so the airflow and fueling stay in proportion.
- EGR and oil system health on the 6.0L: A turbo upgrade on the 6.0L is most effective after the EGR cooler and oil cooler have been addressed. A fresh Garrett unit installed on a 6.0L with a clogged oil cooler will fail prematurely from oil starvation. Fix the cooling system first.
- Intercooler capacity: A larger turbo moves more air at higher temperatures. A quality intercooler upgrade keeps charge temps in check and protects the engine from the heat soak that limits power on a hot day or during sustained towing.
For turbocharger actuators, rebuild kits, and related hardware, browse the turbo actuator collection.
Signs Your Power Stroke Turbo Needs Attention
Common symptoms across all Power Stroke turbo generations:
- Low boost pressure or a boost gauge reading below target on a known-good tune
- Excessive black smoke under load that does not clear with throttle input
- Turbo lag or sluggish spool at low RPM where response used to be sharp
- Limp mode triggered by boost or VGT fault codes -- P0046, P0299, P003A on the 6.0L and 6.7L
- Oil in the intake charge piping or intercooler -- indicates a failed turbo seal
- Whine, grind, or chirp from the turbo housing at any RPM
- Elevated EGTs under normal towing load compared to previous baseline
A turbo with failed vane actuation on the 6.0L or 6.7L will not respond to boost commands from the ECM. The truck may start and idle normally but fall into limp mode under load. Confirm the vane actuator is moving freely before assuming the turbo itself is the fault -- a seized actuator on an otherwise healthy unit can be serviced without replacing the entire turbocharger.
Frequently Asked Questions
Does the Garrett PowerMax fit the 6.7L without custom piping?
Yes. The Garrett PowerMax AVNT3788R units for the 2015-2019 6.7L are direct-fit replacements that bolt to the factory location using the factory inlet and outlet connections. No custom fabrication or modified charge piping is required.
Can I upgrade just the high-pressure turbo on a 6.7L compound setup?
Yes. The Garrett PowerMax and ATS Aurora units listed here are high-pressure turbo upgrades for the factory compound arrangement. The low-pressure turbo remains in place. This is the most common upgrade path on the 6.7L and does not require converting to a single-turbo setup.
Is the 6.0L GT3788VA the same unit as the 6.0L OEM turbo?
The Garrett GT3788VA and PowerMax GT3788VA use the same turbine housing and inlet configuration as the OEM unit, making them direct-fit replacements. The PowerMax version includes upgraded internal components for improved efficiency and output over the original Garrett OEM spec.
Bottom Line
For a tuned 6.7L Power Stroke (2015-2019), the Garrett PowerMax AVNT3788R is the best Power Stroke turbocharger upgrade for most owners -- it delivers a real airflow improvement, bolts directly to the factory location, and is sized correctly for a stage 2-3 tune without custom piping. For a 6.0L with VGT problems or targeting more power, the Garrett GT3788VA PowerMax is the right direct-fit solution. Match the turbo to the injectors and the tune, and the Power Stroke will reward that investment with strong, consistent boost across the RPM range.
