A 6.7L Power Stroke oil cooler failure is worth catching early on the 2011 to 2019 Ford Scorpion diesel, because a restricted cooler quietly raises temperatures and stresses the rest of the cooling system. The oil cooler is a heat exchanger that sits between the oil and the coolant, and when it clogs it cannot control oil temperature or move coolant the way it should. That leads to high oil temperatures, overheating under load, and added strain on the EGR cooler and other components. The good news is that a 6.7L Power Stroke oil cooler problem is straightforward to confirm and fix once you know what to look for. This guide covers the symptoms, why it clogs, how to confirm it before buying parts, and how to replace it right.
What the oil cooler does and why it matters
The 6.7 Power Stroke uses an oil-to-coolant oil cooler, and coolant flows through it to control oil temperature while the same circuit feeds the rest of the cooling system, including the EGR cooler. Because the oil cooler is part of that shared coolant path, a restriction there raises temperatures and adds load to the downstream components. Keeping the oil cooler flowing freely protects the whole cooling circuit, not just oil temperature, which is why it is one of the first things to check when a 6.7 runs hot.
Symptoms of a failing oil cooler
The signs build gradually and get worse under load. Watch for:
- High oil temperature and overheating, especially when towing or working the truck.
- A growing split between oil temperature and coolant temperature on a scan tool.
- Added strain on the EGR cooler, sometimes showing up as EGR trouble.
- Coolant in the oil or oil in the coolant if the cooler cracks internally.
- Reduced heater output and general cooling system stress.
The oil-to-coolant temperature split is the giveaway, and it is the fastest way to confirm the problem without guessing.
Why the 6.7 oil cooler clogs
The oil cooler has small coolant passages, and over time they plug with debris, coolant scale, and breakdown from neglected or contaminated coolant. As the passages restrict, coolant cannot move through the cooler fast enough, oil temperature climbs, and the shared cooling circuit runs hotter. This is a maintenance-driven failure more than an age one, so trucks with stretched coolant service intervals or contaminated coolant are the ones that suffer. That is also why a proper repair includes flushing the system, not just swapping the cooler.
How to confirm it before buying parts
Watch the oil and coolant temperature split
With a scan tool, compare engine oil temperature to engine coolant temperature once warmed up. On a healthy 6.7 they track closely. A large and growing split, with oil temperature running well above coolant temperature under load, points squarely at a restricted 6.7L Power Stroke oil cooler.
Check for cooling system restriction
Look at overall cooling performance and how the truck holds temperature when towing. A 6.7 that runs hot under load or shows EGR strain is often being held back by a plugged oil cooler.
Inspect for cross-contamination
If oil and coolant are mixing, the cooler has cracked internally and needs replacement. Confirm this before assuming a head gasket, since a failed oil cooler can mimic some of those symptoms.
How to replace it right
Replacing the 6.7L Power Stroke oil cooler is an involved job, so do it thoroughly while you are in there. Install a new oil cooler with fresh gaskets, and flush the cooling system to clear the debris and scale that plugged the old one, because leftover contamination will plug a new cooler too. Refill with the correct coolant and bleed the system properly. On a truck that tows or works hard, a high-capacity oil cooler is worth considering, since more cooling capacity keeps oil temperatures down and adds margin under heavy load. If the cooling system has run hot for a while, inspect the EGR cooler at the same time so you address the whole circuit.
When you are ready for parts, a complete 6.7L Power Stroke oil cooler kit gives you the cooler and the gaskets to do the job once, and you can find oil coolers and related cooling parts in our oil cooler section. If you are also chasing coolant loss, our guide on the 6.7L Power Stroke EGR cooler vs EGR valve covers that failure so you address the whole cooling circuit.
Prevent a repeat
The oil cooler is a maintenance item in practice, so treat it like one. Run clean, correct coolant, change it on schedule, add coolant filtration if you tow or work the truck, and keep an eye on the oil-to-coolant temperature split so you catch a restriction early. Flushing the system during the repair and staying on top of coolant service is what keeps a fresh oil cooler flowing and protects the components downstream.
Frequently Asked Questions
What is the first sign of a 6.7 oil cooler problem?
A growing split between oil temperature and coolant temperature on a scan tool is the clearest early sign of a 6.7L Power Stroke oil cooler restriction, often alongside high oil temperature or overheating under load.
Can a bad oil cooler affect the EGR cooler?
Yes. The oil cooler shares the cooling circuit, so a restriction raises temperatures and adds strain on the EGR cooler and other components. Addressing the oil cooler protects the rest of the system.
Do I need to flush the cooling system?
Yes. The debris and scale that plugged the old oil cooler will plug a new one if left in the system, so flushing during the repair is essential to a lasting fix.
Is a high-capacity oil cooler worth it?
If you tow or work the truck hard, a high-capacity oil cooler adds cooling margin and helps keep oil temperatures down under heavy load, which is a worthwhile upgrade during the repair.
Bottom line
A 6.7L Power Stroke oil cooler failure raises oil temperatures, overheats the engine under load, and strains the rest of the cooling circuit, so catching it early matters. Confirm it with the oil-to-coolant temperature split, then replace the cooler with fresh gaskets, flush the system, and consider a high-capacity cooler if you tow. Keep the coolant clean going forward, and the whole cooling circuit stays healthy.
